Single acting low cylinders – 700 bar – SRB

Steel

Features
Note

Features

• Single acting, spring return
• Fitted with removable grooved saddle
• Salt bath nitriding piston rod
• Fitted in standard with HF 738 coupler
• Cylinder SRB 935 with carrying handles

Note

When used, make sure that the cylinder is absolutely steady

Print this sheet

Single acting low cylinders – 700 bar – SRB : Lifting steel cylinders 700 bar - Quiri - 2

Cylinder category	Maxi. force 700 bar	Stroke	Effective area	Oil volume	Reference	Dimensions (mm)												Weight
Cylinder category	Maxi. force 700 bar	Stroke	Effective area	Oil volume	Reference	a	b	b’	c	d	h	i	j	k	m	n	o	Weight
Tons	kN	mm	cm2	cm3		a	b	b’	c	d	h	i	j	k	m	n	o	kg
11	111,3	38	15,9	60	SRB 113	45	92	106	89	75	17	70	39	27	9	2	18	2,7
23	232,2	41	33,18	133	SRB 234	65	99	120	97	94	17	70	54	39	12	2	23	4,8
31	309,1	60	44,18	261	SRB 316	75	120	140,5	117,5	104	17	70	57,15	39	12	2,5	23	6,9
54	549,5	53	78,54	416	SRB 545	100	127	152	124	136	18	70	80	56	12	3	27	12,8
93	928,7	56	132,73	743	SRB 935	130	142	174,5	139,5	174	22	70	105	73,5	12	2,5	35	23,9

Product accessories

Find our guide about couplers on this page: Couplers fitted on single acting QUIRI 700 cylinders

TPP – Flat saddles – 700 bar

Standard saddles delivered on QUIRI 700 cylinders. Protect piston rod end.

TPA – Flat saddles – 700 bar

Standard saddles delivered on QUIRI 700 cylinders. Protect piston rod end.

TRP – Tilt saddles – 700 bar

Correct the effects of a non centered load.
