Single acting, load return – 700 bar – SEG

Steel

Features

• Single acting, load return
• Fitted with removable grooved saddle
• Salt bath nitriding piston rod
• Fitted in standard with HF 738 coupler

Options

F 2 base threaded mounting holes

Print this sheet
Single acting, load return – 700 bar – SEG : Lifting steel cylinders 700 bar - Quiri - 2
Cylinder

 category

 Maximum force

700 bar



 Stroke Effective

area

 Oil volume Reference Dimensions (mm) Option F Weight
a b b’ c d h i j k m n o M x p sur  g
Tonnes kN mm cm2 cm3 kg
11 111,3 38 15,9 60 SEG113 45 109 125 107 60 23 70 39 27 9 2 18 M6 x 8 sur ø 40 2,2
23 232,2 50 33,18 166 SEG235 65 124 145 122 85 23 70 54 39 12 2 23 M6 x 8 sur ø 59 5
31 309,1 50 44,18 221 SEG315 75 125 146 123 100 23 70 57,15 39 12 2 23 M8 x 10 sur ø 65 6,9
54 549,5 50 78,54 393 SEG545 100 138 162 135 130 23 70 80 56 12 3 27 M8 x 10 sur ø 90 12,9
93 928,7 50 132,73 664 SEG935 130 132 164 127 160 23 70 105 73,5 12 3 35 20

Product accessories

Find our guide about couplers on this page: Couplers fitted on single acting QUIRI 700 cylinders

TPP – Flat saddles – 700 bar

Standard saddles delivered on QUIRI 700 cylinders. Protect piston rod end.

TPA – Flat saddles – 700 bar

Standard saddles delivered on QUIRI 700 cylinders. Protect piston rod end.

TRP – Tilt saddles – 700 bar

Correct the effects of a non centered load.
