Single acting cylinders, spring return (5 to 16 T) – 700 bar – SER

Steel

Features

Features

• Single acting, spring return
• Collar thread with rubber protection
• Threaded piston end with removable grooved saddle
• 2 base threaded mounting holes
• Salt bath nitriding piston rod
• Fitted in standard with HF 738 coupler

Print this sheet

Single acting cylinders, spring return (5 to 16 T) – 700 bar – SER : Lifting steel cylinders 700 bar - Quiri - 2

Cylinder category	Maximum force 700 bar	Stroke	Effective area	Oil volume	Reference	Dimensions (mm)																Weight
						a	b	b’	c	d	e	f	M x p sur g	h	i	j	k	l	m	n	o

Tonnes	kN	mm	cm2	cm3																		kg

5	49,5	25	7,06	18	SER52	30	110	125	102	40	11/2-16UN	29	1/4-20UNC x 12 sur ø25	20	70	26	26	3/4-16 UNF	16	6	21	1
		75		54	SER57		160	175	152													1,45
		125		90	SER512		212	227	204													1,92
		175		126	SER517		273	288	271													2,48
		225		162	SER522		324	339	322													2,94
11	111,3	25	15,9	40	SER112	45	119	138	111	60	21/4-14UNS	27	5/16-18UNC x 15 sur ø40	20	70	39	40	1-8 UNC	17	6	25	2,4
		50		80	SER115		144	163	136													2,9
		100		160	SER1110		194	213	186													3,9
		150		240	SER1115		244	263	236													4,9
		200		320	SER1120		298	317	290													6
		250		400	SER1125		348	367	340													7
16	166,3	25	23,75	60	SER162	55	124	159	112	70	23/4-16UN	30	3/8-16UNC x 15 sur ø48	20	70	46	45	1-8 UNC	17	10	25	3,45
		50		120	SER165		149	164	137													4,15
		100		240	SER1610		200	215	188													5,55
		150		360	SER1615		252	267	240													7
		200		480	SER1620		309	324	297													8,6
		250		600	SER1625		362	377	350													10,1
