Single acting cylinders, load return, high tonnage – 700 bar – SGL

Steel

Features

• Single acting, load return
• Fitted with removable grooved saddle
• Chrome plated piston rod
• Fitted in standard with HF 738 coupler
• 2 transport eye hooks

Print this sheet
Single acting cylinders, load return, high tonnage – 700 bar – SGL : Lifting steel cylinders 700 bar - Quiri - 2
Cylinder

category

 Maximum force

700 bar



 Stroke Effective

area

 Oil volume Reference Dimensions (mm) Weight
a b b’ c d h i j k m n o
Tons kN mm cm2 cm3 kg
200 1983,7 50 283,53 1417 SGL2005 190 219 266 212 242 62 70 150 113 13 5 52 70,8
150 4252 SGL20015 319 366 312 95,3
300 3034,6 150 433,74 6506 SGL30015 235 371 437 361 302 78 70 170 130 25 5 71 183
250 10843 SGL30025 481 547 471 234
400 4005,9 150 572,5 8590 SGL40015 270 381 466 372 349 88 70 210 160 25 5 90 259
240 13741 SGL40024 481 566 472 314
500 5111,8 150 730,62 10960 SGL50015 305 400 500 391 392 91 70 240 180 25 5 105 343
190 13882 SGL50019 450 550 441 367

Product accessories

Find our guide about couplers on this page: Couplers fitted on single acting QUIRI 700 cylinders

TPP – Flat saddles – 700 bar

Standard saddles delivered on QUIRI 700 cylinders. Protect piston rod end.

TPA – Flat saddles – 700 bar

Standard saddles delivered on QUIRI 700 cylinders. Protect piston rod end.

TRP – Tilt saddles – 700 bar

Correct the effects of a non centered load.
