Lock nut cylinders, load return – 700 bar – SGS

Steel

Features

• Single acting, load return
• Threaded piston end with flat grooved saddle
• Salt bath nitriding piston rod and lock nut
• Fitted in standard with HF 738 coupler
• Cylinder SGS5415 with carrying handles
• Cylinder SGS9315 and SSL with 2 transport eye hooks

Options

F : 2 base threaded mounting holes

Print this sheet
Lock nut cylinders, load return – 700 bar – SGS : Lifting steel cylinders 700 bar - Quiri - 2
Cylinder

category

 Maximum force

700 bar



 Stroke Effective

area

 Oil volume Reference Dimensions (mm) Option F Weight
a b b’ c d e f h i j * k m n o M x p on g
Tons kN mm cm2 cm3 kg
31 309,1 150 44,18 660 SGS3115 75 274 295 272 100 100 25 23 70 21/4×5 39 12 2 23 M8x10 sur  ø 65 14,5
54 549,5 150 78,54 1176 SGS5415 100 293 317 290 130 129 31 23 70 80×5 56 12 3 27 M8x10 sur  ø 90 27,2
93 928,7 150 132,73 1992 SGS9315 130 325 357 322 175 169 36 47 70 105×5 73,5 12 3 35 M10x15 sur  ø 110 56,4
200 1983,7 150 283,52 4252 SSL20015 190 374 421 367 242 241 57 62 70 160×5 113 13 5 52 125
300 3034,6 150 433,73 6506 SSL30015 235 435 501 428 302 302 69 78 70 180×5 130 25 5 71 222
250 10843 SSL30025 545 611 538 269
400 4005,9 150 572,5 8590 SSL40015 270 450 535 443 349 348 74 88 70 220×5 160 25 5 90 315
240 13740 SSL40024 550 635 543 375
500 5111,8 150 730,62 10960 SSL50015 305 475 575 468 392 392 80 91 70 260×5 180 25 5 105 427
190 13881 SSL50019 525 625 518 458

* : Trapezoidal threading
