Extra flat «plate» cylinders – STA

Features

• Single acting, load return
• Chrome plated piston rod
• End of stroke red visual mark
• Cylinders 100T and 500T with 2 transport eye hooks

Nota

Please assure that the cylinder base and the piston contact side are perfectly parallel. STA cylinders does not accept any excentric load.

Print this sheet
Extra flat «plate» cylinders – STA : Lifting steel cylinders 700 bar - Quiri - 2
Cylinder category Maximum force at

800 bar

 Stroke Effective area Oil volume Reference Dimensions (mm) Weight
a b c e h
Tons kN mm cm2 cm3 kg
10 100,5 10 12,56 13 STA 10/10 40 38 25 78 15,5 1,4
25 249,3 12 31,17 37,4 STA 25/12 63 40 35 108 15,5 2,9
40 401,9 14 50,26 70 STA 40/14 80 45 45 128 15,5 4,6
60 628 16 78,54 126 STA 60/16 100 50 55 158 15,5 7,8
100 981,3 16 122,7 200 STA 100/16 125 63 70 188 15,5 14
160 1607,7 18 201,1 362 STA 160/18 160 78 90 245 27 29
250 2512 20 314,2 630 STA 250/20 200 95 115 310 32 56
500 4923,5 25 615,7 1540 STA 500/25 280 134 160 430 50 152

Couplers

Extra flat «plate» cylinders – STA : Lifting steel cylinders 700 bar - Quiri - 3

PM115 + A31048 + A52084
