Extra flat cylinders with safety nut – 700 bar – SSP
Steel
• Single acting with gravity return
• Body, rod and safety nut in sulphonitrided steel
• Stroke-limiting port prevents accidental piston extension
• Supplied as standard with HF738 coupling
• Integral swivel head, up to 5° depending on model,
• Robust design accepts up to 10% radial load,
• see table below
Ensure that the bottom of the cylinder is fully supported when in use.
| Cylinder
category
|
Maxi. force
700 bar
|
Stroke | Head
angle of inclination |
Maximum radial
load resistance |
Effective
area |
Oil volume | Reference | Dimensions (mm) | Weight | |||||||||
| a | b | d | f | h | i | j | k | o | ||||||||||
| Tons | kN | mm | ° | % | cm2 | cm3 | kg | |||||||||||
| 35 | 351.7 | 45 | 5 | 10 | 50 | 226 | SSP 35 | 80 | 125 | 105 | 22 | 15.5 with 7° angle | 70 | M80 x 4 | 66 | 5 | 8.5 | |
| 60 | 605.8 | 45 | 5 | 10 | 87 | 389 | SSP 60 | 105 | 121 | 140 | 24 | 19.5 with 6° angle | 70 | M105 x 4 | 96 | 7 | 14 | |
| 100 | 1001.5 | 45 | 5 | 10 | 143 | 644 | SSP 100 | 135 | 132 | 173 | 28 | 26.5 | 70 | M135 x 4 | 126 | 8 | 24 | |
| 150 | 1588.1 | 45 | 5 | 8 | 227 | 1021 | SSP 150 | 170 | 68 | 220 | 36 | 27.5 | 70 | M170 x 4 | 160 | 10 | 43 | |
| 200 | 1983.7 | 45 | 5 | 8 | 283 | 1275 | SSP 200 | 190 | 154 | 245 | 38 | 29.5 | 70 | M190 x 4 | 180 | 10 | 55 | |
| 250 | 2540.1 | 45 | 5 | 5 | 363 | 1633 | SSP 250 | 215 | 157 | 275 | 35 | 32.5 | 70 | M215 x 4 | 200 | 13 | 70 | |
| 400 | 4005.9 | 45 | 4 | 5 | 572 | 2575 | SSP 400 | 270 | 177 | 350 | 42 | 38.5 | 70 | M270 x 4 | 252 | 13 | 129 | |
| 500 | 4945.5 | 45 | 3 | 5 | 707 | 3179 | SSP 500 | 300 | 190 | 400 | 47 | 42.5 | 70 | M300 x 4 | 290 | 11 | 182 | |
Product accessories
Find our guide about couplers on this page: Couplers fitted on single acting QUIRI 700 cylinders
