Step cylinders, spring return – 500 bar – SLB

Light alloy

Features

Single acting, spring return
Corrosion resistant light alloy body and piston rod
Fitted with :
– Light alloy support frame
– Strap carrying handles
– Specially fitted with RM 518 coupler

Print this sheet

These cylinders can also be made with hydraulic return, please contact us

Step cylinders, spring return – 500 bar – SLB : Lifting light alloy cylinders 500 bar - Quiri - 2
Cylinder category Working force
500 bar		 Stroke Effective area Oil volume Reference Dimensions (mm) Weight
Tons kN mm cm2 cm3   a b d e kg
45 475 200 95,03 1901 SLB 45/200 110 385 145,5 150 46
75 769,3 200 153,93 3079 SLB 75/200 140 415 190,5 150 60
110 1134,4 200 227 4540 SLB 110/200 170 440 230,5 155 82
Cylinder category Support blocks, standard height 150 mm
Under support frame Under piston rod
Tons Dimensions (mm) Weight (kg) Reference Dimensions (mm) Weight (kg) Reference
45 350 x 90 13 CEB 45 350 x 130 13,5 CEP 45
75
110 350 x 150 16,5 CEP 110

Working

Step cylinders, spring return – 500 bar – SLB : Lifting light alloy cylinders 500 bar - Quiri - 3

1 : Installation
2 : First lift
3 : Support block installation
4 : Piston return
5 : Under piston block installation
6 : Second lift
7 : Support block installation
8 : Piston return
9 : Third lift
10 : Etc……….
