Single acting cylinders, load return – 500 bar – SLS

Light alloy

Features

• Single acting, load return
• Maximum pressure : 600 bar (stroke to be limited at 80% of the whole stroke)
• Corrosion resistant light alloy body (except 6T model in steel)
• Chrome plated piston rod
• Wiper seal
• Delivered in standard without coupler

Options

F : 4 base threaded mounting holes
T : Threading of the hole ø16mm on SLS 6/20

Print this sheet
Single acting cylinders, load return – 500 bar – SLS : Lifting light alloy cylinders 500 bar - Quiri - 2
Single acting cylinders, load return – 500 bar – SLS : Lifting light alloy cylinders 500 bar - Quiri - 3
Cylinders category Working force

500 bar

 Maxi force

600 bar

 Stroke Effective area Oil volume Reference Dimensions (mm) Option F Weight
a b c d h j M x p on Øg
Tons kN kN mm cm2 cm3 kg
6 62,8 75,4 20 12,56 25 SLS 6/20 40 62 61 22 32 0,7
10 98,2 117,8 30 19,63 59 SLS 10/30 50 120 117 68,5 21 40 M6 x12 on Ø50 1,8
20 192,4 230,8 30 38,48 115 SLS 20/30 70 105 104 100,5 21 60 M8 x 12 on Ø80 3,3
45 475 569,9 30 95,03 285 SLS 45/30 110 145 142 145,5 25 95 M10 x 15 on Ø120 11
75 769,3 923,2 30 153,93 462 SLS 75/30 140 170 167 190,5 25 125 M10 x15 on Ø160 15
110 1134,4 1361,2 30 227 681 SLS 110/30 170 190 187 230,5 30 150 M12 x 20 on Ø190 24,5
