Hollow piston single acting cylinders, load return – 500 bar – SLC

Light alloy

Features
Options

Features

• Single acting, load return
• Maximum pressure 600 bar (stroke to be limited at 80% of the whole stroke)
• Corrosion resistant light alloy body
• Chrome plated piston rod for cylinder 13 T
• Corrosion resistant light alloy piston rod for cylinders 35, 55, 80 T
• Wiper seals
• Delivered in standard without coupler

Options

A+B : Body collar thread with rubber protection *
F : 4 base threaded mounting holes

Print this sheet

Hollow piston single acting cylinders, load return – 500 bar – SLC : Lifting light alloy cylinders 500 bar - Quiri - 2

Cylinder category	Working force 500 bar	Maximum force 600 bar	Stroke	Effective area	Oil volume	Reference	Dimensions (mm)								Options			Weight
							a	b	c	d	h	j	a1	q	Option A *		Option F
															e	f	M x p on Øg
Tons	kN	kN	mm	cm2	cm3										e	f	M x p on Øg	kg
13	129,6	155,6	100	25,92	260	SLC 13/100	70	225	222	100,5	28	55	40	27	M100 x 2	40	M8 x 20 on Ø 65	6,5
35	333,8	400,5 *	100	66,76	670	SLC 35/100	110	240	236	145,5	43	85	60	44	145 x 3 **	45	M10 x 22 on Ø 90	10,2
35	333,8	400,5 *	200	66,76	1340	SLC 35/200	110	370	364	145,5	43	85	60	48	145 x 3 **	45	M10 x 22 on Ø 90	14,6
55	548,8	658,5 *	100	109,76	1100	SLC 55/100	140	270	266	190,5	55	110	75	55	190 x 4 **	50	M10 x 22 on Ø 120	22
80	816,8	980,1 *	100	163,36	1640	SLC 80/100	170	290	285	230,5	55	140	90	70	225 x 5 **	50	M12 x 25 on Ø 150	32,2

* For 35, 55, and 80 T cylinders with Option A, maximum pressure is 500 bar

** Semi-trapezoidal threading
