Pressure gauges
Standard pressure gauges
Single scale (bar)
Accuracy: ± 1% to 2,5% of full scale
| Size | Reference | Scale
(bar) |
Connection | |
| Dry | Glycerine filled | |||
| 63 | MG 016 | 0 – 160 | G 1/4’’ | |
| MG 025 | 0 – 250 | |||
| MG 040 | 0 – 400 | |||
| MG 060 | 0 – 600 | |||
| MG 070 | 0 – 700 | |||
| MG 0100 | 0 – 1000 | |||
| 100 | MS 116 * | MG 116 | 0 – 160 | G 1/2’’ |
| MS 125 * | MG 125 | 0 – 250 | ||
| MS 140 * | MG 140 | 0 – 400 | ||
| MS 160 * | MG 160 | 0 – 600 | ||
| MG 1100 | 0 – 1000 | |||
| MG 1500 | 0 – 1600 | 1/2’’ NPT | ||
| 160 | MG 1600 | 0 – 1600 | G 1/2’’ | |
* On request, we can deliver a twin scale (bar and ton or kN) on dry 100 mm gauges only
MS116 and MS160 with maximum indicating pointer
ø100 mm glycerine filled pressure gauges : specific to QUIRI 700 cylinders
Scales in PSI and bar (kg/cm²)
G3/8’’ rotating bottom connection
Accuracy : ± 2,5% of full scale
| Scale (Ton) | Reference | To use with cylinder… |
| 5 – 11 | MG 511 | SER 5 – 11 |
| SEG 11 | ||
| SRP 5 – 11 | ||
| 16 – 23 | MG 1623 | SER 16 – 23 |
| SEG 23 | ||
| SRP 23 | ||
| DE 23 | ||
| 31 – 54 | MG 3154 | SER 31 – 54 |
| SEG 31 – 54 | ||
| SRP 31 – 54 | ||
| SGS 31 – 54 | ||
| DE 31 -54 | ||
| 31 – 54 – 93 | MG 93 | SER 93 |
| SEG 93 | ||
| SRP 31 – 54 – 93 | ||
| SGS 93 | ||
| DE 93 | ||
| 12 – 20 | MG 1220 | CSE 12 – 20 |
| 29 – 58 | MG 2958 | CSE 29 – 58 |
| CDE 29 – 58 | ||
| MG 700 | All cylinders |
