Double acting hand pumps, 2 speeds – 700 bar – PMD

For double acting cylinders

Features

• 2 automatic speeds
• External adjustable pressure relief valve, set at 700 bar
• Delivered with oil

Options

Other relief valve setting : on request

Print this sheet
Double acting hand pumps, 2 speeds – 700 bar – PMD : Hydraulic hand pumps 700 bar - Quiri - 2
Pressure oil flow Max pressure Oil flow Oil capacity Max handle effort Reference Dimensions (mm) Weight
a b c d e f f ’ g h i j k l m n o
bar cm3/pump stroke bar cm3/pump stroke Total Usable
BP HP cm3 cm3 daN kg
15 19 700 2.5 3200 3000 50 PMD 733 730 665 125 568 12 185 595 93 607 4xM8 110 40 25 30 20 80 17
6200 6000 50 PMD 736 730 665 125 510 10 185 595 151 2xM6 165 68 25 41 20 130 23
12200 12000 50 PMD 7312 730 665 125 510 10 185 595 290 130 25 41 20 28

Product accessories

ø 100 pressure gauge adaptor – 700 bar – AM 135

ø 100 pressure gauge – 700 bar

Standard Thermoplastic hoses (internal Ø 6mm) – 700 bar

Internal 6mm

View similar products

Double acting light alloy hand pumps, 2 speeds – 700 bar – QDH

For double acting cylinders

Single acting hand pumps, 2 speeds – 700 bar – PMS

For single acting cylinders

Single acting hand pumps, 1 speed – 700 bar – PMS

For single acting cylinders

Single acting light alloy hand pumps, 2 speeds – 700 bar – QSH

For single acting cylinders
