Single acting 1000 bar hand pumps, 2 speeds (SA25 + 8) – SA

For single acting cylinders

Features

• 2 automatic speeds
• Pressure relief valve, set at 1000 bar
• Delivered with oil

Options

• Other relief valve setting : on request
• M6 fixing holes

Print this sheet
Single acting 1000 bar hand pumps, 2 speeds (SA25 + 8) – SA : Hydraulic hand pumps 1000 bar - Quiri - 2
Pressure Oil flow Maximum

pressure

 Oil flow Oil capacity Maxi. handle

effort



daN

 Reference * Dimensions (mm) Weight
a b c d e f f ’ g h j
bar cm3/pump stroke bar cm3/pump stroke Total Usable kg
LP HP cm3 cm3
80 11 1000 1,13 1900 1500 30 SA25+8 R1,5 653 76 80 117 117 225 590 42 27,5 38 31 9
6900 6000 30 SA25+8 R6 633 140 80 117 117 225 590 42 27,5 38 31 16
12500 10000 30 SA25+8 R10 633 250 80 117 117 225 590 42 27,5 38 31 23

* Warning : To use this pump, it must be fitted with its accessories : block, adaptor, pressure gauge and hose (see below).

HOSES WITH COUPLERS

Single acting 1000 bar hand pumps, 2 speeds (SA25 + 8) – SA : Hydraulic hand pumps 1000 bar - Quiri - 3
Standard length * Reference
1 A38055
2 A38056
3 A38057

* Other length on request

BLOCKS – PRESSURE GAUGES – ADAPTORS

Blocks
Nbr of outlets Reference
1 MF31
2 MF32
3 MF33
Pressure gauges + adaptors
Size References
ø 63 MG 0100 + AM 014
ø 150 MG 1600 + AM 112
