Mounting accessories for 500V series cylinders

Print this sheet
Mounting accessories for 500V series cylinders : 500 bar hydraulic cylinders - Quiri

Front endeye

Bore Dimensions Reference
c d f g
25 35 30 48 M 12 x 1 816034
32 42 36 58 M 14 x 1 816041
40 52 42 70 M 18 x 1.5 816048
50 70 50 85 M 24 x 1.5 816055
63 83 62 107 M 27 x 1.5 817034
80 110 75 130 M 35 x 1.5 817041
100 130 95 165 M 45 x 1.5 817048
125 170 120 210 M 55 x 1.5 818034
140 190 135 235 M 64 x 1.5 818041
160 212 150 260 M 72 x 1.5 818048
200 270 183 323 M 90 x 2 819041

Cylinder mounting

Bore Dimensions Center distance X
S tole. M7 d
25 26 18 176
32 30 22 206
40 35 28 245
50 47 35 275
63 62 45 342
80 75 55 400
100 90 70 480
125 120 90 595
140 130 100 650
160 150 110 710
200 180 140 863

The endeyes can be completed with :

Sealed ball joints with 2 snap rings and grease nipple

Ordering data for grease nipples : Ø 25 A99087 or A99016

Mounting accessories for 500V series cylinders : 500 bar hydraulic cylinders - Quiri - 2
Bore Dimensions Ball joint

reference

 Snap ring

reference
h i alpha
25 15 12 9° A 68010 AQ 2026
32 17 14 10° A 68011 AQ 2030
40 20 16 16° A 68012 AQ 2033
50 30 22 7° A 68013 AQ 2051
63 40 28 7° A 68014 AQ 2055
80 50 35 7° A 68015 AQ 2060
100 60 44 7° A 68016 AQ 2077
125 80 55 6° A 68017 AQ 2079
140 90 60 5° A 68018 AQ 2080
160 100 70 7° A 68019 AQ 2081
200 120 85 6° A 68021 AQ 2084

Bronze bushing

.

Mounting accessories for 500V series cylinders : 500 bar hydraulic cylinders - Quiri - 3
Bore Dimensions References
k m
25 18 20 816035
32 22 24 816042
40 28 30 816049
50 35 37 816056
63 45 47 817035
80 55 57 817042
100 72 72 817049
125 100 92 818035
140 110 105 818042
160 125 115 818049
200 160 145 819042
Mounting accessories for 500V series cylinders : 500 bar hydraulic cylinders - Quiri - 4

Trunnion plate

Bore Dimensions References
a b c r
25 18 60 96 20 816031
32 22 75 119 25 816038
40 28 85 141 30 816045
50 35 110 180 40 816052
63 45 150 240 50 817010
80 55 190 300 60 817038
100 63 220 346 70 817045
125 80 245 405 90 818031
140 85 270 440 90 818038
160 95 310 500 100 818045
200 115 380 610 120 819038

Flange

Bore Dimensions Flange

reference

 Spacer

reference
d f g h i n m*
25 11 70 90 15 0 4 50 816030 –
32 11 82 105 15 5 6 60 816037 –
40 13 100 135 20 5 6 70 816044 –
50 15 125 165 20 15 6 90 816051 –
63 17 135 185 20 25 8 106 817030 –
80 21 170 210 25 25 8 140 817037 817037/002
100 23 205 250 35 25 8 160 817044 817044/002
125 28 270 330 40 40 8 210 818030 818030/002
140 28 300 360 40 40 12 250 818037 818037/002
160 32 320 390 50 40 12 260 818044 818044/002
200 38 410 500 55 55 12 330 819037 819037/002

* d10 tolerance

The flange or trunnion plate must be secured with a clamping nut.

Clamping nut

Bore Dimensions Reference
P – 0

0,5

 k
25 49 10 816032
32 59 10 816039
40 69 10 816046
50 85 15 816053
63 105 15 817032
80 135 20 817039
100 159 20 817046
125 209 25 818032
140 240 30 818039
160 259 35 818046
200 329 40 819039

Cylinder mounting



Bore



 l L t s Y
25 115.5 42.5 18 85.5 75.5
32 129 55 22 93.5 80.5
40 149.5 67.5 28 107.5 92.5
50 172.5 67.5 35 122.5 102.5
63 212 85 45 150 125
80 245 105 55 170 140
100 290 120 70 195 160
125 345 160 90 235 190
140 380 160 100 245 200
160 420 170 110 270 220
200 508 215 140 325 265
