500V series single-acting cylinders

SE - 500V

Features

High-performance cylinders suitable for all applications, particularly in very hard operating conditions with high loads in small spaces (steelworks, public works, presses, etc.).
• Chevron seals on piston and rod for standard version
• Pressure in intermittent service : 500 bar
• Intensive operating : 400 bar
• Maximum speed : 0,5 m/s with standard seals, up to 2 m/s with special seals
• Maximum temperature : 100°C with standard seals, up to 200°C with viton seals

On demand

• Other threads k
• Metric thread on Ø e
• Damping (damping stroke to be specified)
• Double-rod cylinder
• The rear endeye on VO-type cylinders can be supplied in the following versions :
– Ø S smoth
– with ball joint, snap ring and grease nipple
– or with bronze bushing

Print this sheet

Designation

500V series single-acting cylinders : 500 bar hydraulic cylinders - Quiri - 2

Dimensions

500V series single-acting cylinders : 500 bar hydraulic cylinders - Quiri - 3
Bore Ø A 25 32 40 50 63 80 100 125 140 160 200
Rod Ø D 18 22 28 40 50 63 80 100 110 125 160
a 128 148 175 190 235 275 315 385 405 440 540
b 8 8 10 10 15 15 15 20 20 25 30
c 35 42 52 70 83 108 132 170 190 212 270
d 50 60 70 85 105 135 165 210 240 260 330
e 42 52 58 75 95 116 146 186 208 235 290
f 11 12 16 18 20 22 25 35 35 35 40
g 45 47.5 56.5 67.5 82 98 115 135 143 160 195
h G 1/4 G 1/4 G 3/8 G 3/8 G 1/2 G 1/2 G 3/4 G 3/4 G 3/4 G 1 G 1
i 21 21 24 24 31 31 36 36 36 42 42
k M 12 x 1 M 14 x 1 M 18 x 1.5 M 24 x 1.5 M 27 x 1.5 M 35 x 1.5 M 45 x 1.5 M 55 x 1.5 M 64 x 1.5 M 72 x 1.5 M 90 x 2
m 12 14 18 24 27 35 45 55 64 72 90
p 17.5 22.5 32.5 42.5 60 75 90 100 110 125 155
r mini/maxi 15/20 20/25 25/30 35/40 45/50 50/60 60/70 80/90 80/90 90/100 110/120
s 26 30 35 47 62 75 90 120 130 150 180
t 18 22 28 35 45 55 70 90 100 110 140
u 50 50 50 50 50 50 55 70 70 70 80
y 147 170 203 225 280 325 385 475 505 550 680
Stroke mini 20 20 30 30 50 50 50 50 100 100 100
Thread on Ø e M 42 x 1.5 M 52 x 1.5 M 58 x 2 M 75 x 2 M 94 x 2 M 112 x 3 M 140 x 2 M 186 x 3 M 206 x 2 M 255 x 3 M 250 x 3
500V series single-acting cylinders : 500 bar hydraulic cylinders - Quiri - 4

References

Bore / Rod 25/18 32/22 40/28 50/40 63/50 80/63 100/80 125/100 140/110 160/125 200/160
VN bottom Rod F 111036 111031 111041 112022 112033 113035 114020 115010 116042 116048 117044
Rod T 111037 111032 111042 112023 112034 113036 114021 115011 116043 116049 117045
VO bottom Rod F 111038 111033 111043 112024 112035 113037 114022 115012 116044 116050 117046
Rod T 111039 111034 111044 112025 112036 113038 114023 115013 116045 116051 117047

Technical specifications

Single-acting “pull” cylinders, sealed on the return side, are obtained from double-acting cylinders with pull rod; the supply port on the push side, not used in this case, is fitted with an air filter.

Cylinder force in 104 N at 500 bar

Bore 25 32 40 50 63 80 100 125 140 160 200
Section in cm2 4.9 8.04 12.56 19.63 31.17 50.26 78.54 122.71 153.93 201.06 314.16
Pushing force in 104N 2.40 3.94 6.16 9.62 15.28 24.64 38.50 60.15 75.46 98.56 154

Cylinder weight in Kg

Bore 25 32 40 50 63 80 100 125 140 160 200
VN TYPE CYLINDER P 1.37 2.6 3.6 6.5 12 21 40 81 106 142 275
VO TYPE CYLINDER P 1.47 2.8 4 7.3 13 25 47 95 125 166 330
Per stroke mm Z 0.006 0.007 0.011 0.024 0.032 0.054 0.083 0.14 0.17 0.21 0.35

Determining the weight of a cylinder : Weight in kg = P + (Z x stroke in mm)

Numerical example :

Bore Ø 125 VN Type : P=81
Per mm of stroke : Z=0,14
Stroke in mm : 800
Weight =80+(0,14*800) = 193 kg
