500V series plunger cylinders

P - 500V

Features

High-performance cylinders for all applications, particularly suited to very hard operating conditions with high loads in small spaces (steelworks, public works, presses, etc.).
• Chevron seals on piston and rod for standard version
• Pressure in intermittent service : 500 bar
• Intensive operating : 400 bar
• Maximum speed : 0,5 m/s with standard seals, up to 2 m/s with special seals
• Maximum temperature : 100°C with standard seals, up to 200°C with Viton seals

On demand

• Other threads k
• Metric thread on Ø e
• Choice of port connection – head (front) – Bottom (rear)
The other port is blocked by a steel plug and gasket.
• The rear endeye on VO-type cylinders can be supplied in the following versions :
– Ø S smooth
– with ball joint, grease nipple
– or with bronze bushing

Print this sheet

Designation

500V series plunger cylinders : 500 bar hydraulic cylinders - Quiri - 2

Dimensions

500V series plunger cylinders : 500 bar hydraulic cylinders - Quiri - 3
Bore Ø A 25 32 40 50 63 80 100 125 140 160 200
Rod Ø D 18 22 28 40 50 63 80 100 110 125 160
a 106 123 155 158 200 230 255 315 335 375 470
b 8 8 10 10 15 15 15 20 20 25 30
c 35 42 52 70 83 106 132 170 190 212 270
d 50 60 70 85 105 135 165 210 240 250 330
e 42 52 58 75 95 116 146 186 208 235 290
f 11 12 16 18 20 22 25 30 30 30 40
g 42.5 47.5 56.5 67.5 82 98 115 135 145 160 195
h G 1/4 G 1/4 G 3/8 G 3/8 G 1/2 G 1/2 G 3/4 G 3/4 G 3/4 G 1 G 1
j 21 21 24 24 31 31 36 36 36 42 42
k M 12 x 1 M 14 x 1 M 18 x 1.5 M 24 x 1.5 M 27 x 1.5 M 35 x 1.5 M 45 x 1.5 M 55 x 1.5 M 64 x 1.5 M 72 x 1.5 M 90 x 2
m 12 14 18 24 27 35 45 55 64 72 90
p 17.5 22.5 32.5 42.5 60 75 90 100 110 125 155
r mini/maxi 15/20 20/25 25/30 35/40 45/50 50/60 60/70 80/90 80/90 90/100 110/120
s 26 30 35 47 62 75 90 120 130 150 180
t 18 22 28 35 45 55 70 90 100 110 140
u 50 50 50 50 50 50 55 70 70 70 80
y 124 146 175 193 245 280 325 405 435 485 610
Stroke mini 20 20 30 30 50 50 50 50 100 100 100
Thread on Ø e M 42 x 1.5 M 52 x 1.5 M 58 x 2 M 75 x 2 M 94 x 2 M 112 x 3 M 140 x 2 M 186 x 3 M 206 x 2 M 200 x 3 M 250 x 3
500V series plunger cylinders : 500 bar hydraulic cylinders - Quiri - 4

References

Bore / Rod 25/18 32/22 40/28 50/40 63/50 80/63 100/80 125/100 140/110 160/125 200/160
VN bottom F Rod 121020 121026 121032 121038 122020 122026 123020 124010 125010 125016 126016
T Rod 121021 121027 121033 121039 122021 122027 123021 124011 125011 125017 126017
VO bottom F Rod 121022 121028 121034 121040 122022 122028 123022 124012 125012 125018 126018
T Rod 121023 121029 121035 121041 122023 122029 123023 124013 125013 125019 126019

Technical specifications

Cylinder force in 104 N at 500 bar

Bore 25 32 40 50 63 80 100 125 140 160 200
Section in cm2 2.36 4.24 6.4 7.07 11.53 19.09 28.27 44.17 58.9 78.34 113.1
Pushing force in 104N 1.16 2.08 3.14 3.46 5.65 9.36 13.86 21.65 28.87 38.4 55.45

Cylinder weight in Kg

Bore 25 32 40 50 63 80 100 125 140 160 200
VN TYPE CYLINDER P 1.37 2.6 3.6 6.5 12 21 40 81 106 142 275
VO TYPE CYLINDER P 1.47 2.8 4 7.3 13 25 47 95 125 166 330
Per stroke mm Z 0.006 0.007 0.011 0.024 0.032 0.054 0.083 0.14 0.17 0.21 0.35

Determining the weight of a cylinder : Weight in kg = P + (Z x stroke in mm)

Numerical example :

Bore Ø 125 VN Type : P=81
Per mm of stroke : Z=0,14
Stroke in mm : 800
Weight =80+(0,14*800) = 193 kg

Product accessories

Mounting accessories for 500V series cylinders

View similar products

500V series double-acting cylinders

DE - 500V

500V series single-acting cylinders

SE - 500V
