Swing clamp with planar rotation – 160 bar – Electrical sensing of released position PL**XE

Double-acting - planar rotation - electrical sensing
Force at 160 bar: 10 kN

Supply through counter-bores under the flange ring
Fastening with screws

• sensing by inductive sensors,
released position at the base of the cylinder
• adjustable sensor position
• right or left planar rotation, 90° ±2°
• bleeder near clamping and release
• rod indexing
• maximum service pressure: 160 bar

• clamping arm: see accessories section
• 60°, 45° or 0° rotation on request
• cable with M12x1 connector on request

The clamps are supplied with O-rings, lock nut and lock washer (dimensions and tightening torque: see Lock washer for clamp type P11, P21 and Nut for clamp type P31 and P41)
O-rings: 7.65 x 1.78 90 NBR

Print this sheet
Swing clamp with planar rotation – 160 bar – Electrical sensing of released position PL**XE : Swing clamps with position detection - Quiri - 2

Definition of forces depending on clamping arm: consult the guide
Important recommendations: consult the guide

F max

at

160

bar

Rod

ød

Travel Max flow rate

A

Swept volume

A

B

Direction

of rotation

Type Reference
a





c





øD





e





f



span-ner

h





øk1

øk2



L





L1





L2





L3





m





p1





p2





p3





y





kN mm mm l/min cm3 mm mm mm mm mm mm mm mm mm mm mm mm mm mm °
10 36 12 2 41 right PL 31 DX E 192 026/050 18 20 80 M24 x 1.5 10 41 110 319 266 238 43 29 8.5 14 11 45 3D
53 left PL 31 GX E 192 026/150 95 3D
