Universal double-acting swing clamp – 500 bar – Supplied through taps or counter-bores under the head ULT

Double-acting - with rotation travel
Force at 500 bar: 6.5 to 42 kN

Two supply possibilities: taps and counter-bores under the head

Universal double-acting swing clamp – 500 bar – Supplied through taps or counter-bores under the head ULT : Swing clamps with helical rotation - Quiri

Characteristics
Nota

Characteristics

• total travel = rotation travel + linear clamping
travel
• right or left helical rotation, 90°±2°
• with bleeder on clamping or release
• metal scraper as standard
• Max. pressure : 500 bar
• Clamping arm: see BCK, BMK, BLK

Nota

Clamp supplied with plugs and O-rings
(Dimensions and tightening torque : EK).

Print this sheet

Definition of forces depending on clamping arm: see below
Important recommendations: consult the guide

Force with 500 bar	Force with 350 bar	clamping travel	rotation travel	total travel	Section A B	Swept volume A B	Direction of rotation	Indexation	Type	Reference
Force with 500 bar	Force with 350 bar	clamping travel	rotation travel	total travel	Section A B	Swept volume A B	Direction of rotation	Indexation	Type	Reference	a1	a2	a3	b	øc	ød	ød1	e	k1	k2	l	m	n1	n2	n3	øo	øo1	p	q	r1	r2	r3	øw1
kN	kN	mm	mm	mm	cm²	cm³					mm	mm	mm	mm	mm	mm	mm		mm	mm	mm	mm	mm	mm	mm	mm		mm	mm	mm	mm	mm	mm
6.5	4.6	11	8	19	1.76 4.9	3.34 9.31	right	WITHOUT	ULT 15	191 229/000	70	50	26.5	48.5	44.8	20	38	M18x1.5	36	27	78.5	57.5	20	37	26.5	6.6	M6	18	14	26.5	32	28	5
							right	WITH		191 229/050
							left	WITHOUT		191 229/100
							left	WITH		191 229/150
17	11.8	13	9	22	4.52 12.56	9.94 27.63	right	WITHOUT	ULT 25	191 223/000	85	63	34.5	53.5	59.8	32	50	M28x1.5	42	33	94.5	66.5	27	48	38	9	M8	19	14	31	46	41	5
							right	WITH		191 223/050
							left	WITHOUT		191 223/100
							left	WITH		191 223/150
26	18	15	11	26	7.06 19.63	18.35 51.03	right	WITHOUT	ULT 35	192 198/000	110	85	47	68	79.8	40	55	M35x1.5	40	31	104	70	37	65	50	11	M10	15	12	40	62	57	5
							right	WITH		192 198/050
							left	WITHOUT		192 198/100
							left	WITH		192 198/150
42	30	15	11	26	11.53 31.17	31.13 84.16	right	WITHOUT	ULT 45	192 199/000	122	95	55	73	89.8	50	66	M45x1.5	41	32	111	71	42	72	55	13	M12	15	12	45	75	70	5
							right	WITH		192 199/050
							left	WITHOUT		192 199/100
							left	WITH		192 199/150
