Universal double-acting swing clamp – 500 bar – Counter-bored block version UBT

Double-acting - with rotation travel
Force at 500 bar: 6.5 to 42 kN

Block with supply through tapped port

Universal double-acting swing clamp – 500 bar – Counter-bored block version UBT : Swing clamps with helical rotation - Quiri

Characteristics

• treated burnished steel body
• right or left helical rotation, 90°±2°
• total travel = rotation travel + clamping travel
• metal scraper as standard
• max. pressure : 500 bar
• clamping arm: see BCK, BMK, BLK

Options

• clamping arm: see accessories section
• 60°, 45° or 0° angle of rotation on request
• special models on request
• Rod with indexing

Nota

Clamps are supplied with O-rings, lock nut and lock washer
(dimensions and tightening torque : EK).

Print this sheet

Universal double-acting swing clamp – 500 bar – Counter-bored block version UBT : Swing clamps with helical rotation - Quiri - 2

Definition of forces depending on clamping arm: see below
Important recommendations: consult the guide

Force with 500 bar	Force with 350 bar	clamping travel	rotation travel	total travel	Section A B	Swept volume A B	Direction of rotation	Indexation	Type	Reference
Force with 500 bar	Force with 350 bar	clamping travel	rotation travel	total travel	Section A B	Swept volume A B	Direction of rotation	Indexation	Type	Reference	a1	a2	ød	e	k	l	øm	n1	n2	øo	øo1	p
kN	kN	mm	mm	mm	cm²	cm³					mm	mm	mm		mm	mm	mm	mm	mm	mm	mm	mm
6.5	4.62	7	7	14	1.76 4.9	2.47 6.86	right	WITHOUT	UBT 15	191 255/000	65	45	20	M18 x 1.5	71	110	3	50	30	8.5	14.5	63
							right	WITH		191 255/050
							left	WITHOUT		191 255/100
							left	WITH		191 255/150
17	11.76	8	8	16	4.52 12.56	7.23 20.10	right	WITHOUT	UBT 25	191 261/000	85	63	32	M28 x 1.5	91	139	4	63	40	10.5	17.5	81
							right	WITH		191 261/050
							left	WITHOUT		191 261/100
							left	WITH		191 261/150
42	30.24	11	9	20	11.53 31.17	23.06 62.34	right	WITHOUT	UBT 45	192 234/000	125	95	50	M45 x 1.5	110	175	4	95	65	17	25.5	94
							right	WITH		192 234/050
							left	WITHOUT		192 234/100
							left	WITH		192 234/150
