Short clamping arm – rod with 15° taper – For swing clamp size: 11 – 12 – 21 – 31 – 41 BC

for swing clamp size: 11 - 12 - 21 - 31 - 41
rod end with 15° taper

Definition

Available as standard in three versions:
• with bevels
• with bevels and indexing
• with no bevels, with indexing.

Characteristics

• turns over 360°
• treated for corrosion protection
• material: 2C45
• maximum service pressure: 250 bar

Option

Special arms made on request.

Nota

The clamping force and maximum flow rate reduce as the arm length increases (see tables on the guide and Long clamping arm BLK).

Make sure the rod is held while fastening the screw.
see figure 1 on the guide

Print this sheet

Short clamping arm – rod with 15° taper – For swing clamp size: 11 – 12 – 21 – 31 – 41 BC : Swing clamps with helical rotation - Quiri - 2

Tap	Bevels	Indexing	Type	Reference
Tap	Bevels	Indexing	Type	Reference	a	b	c	ød	e	f	h	k	l	øn	øo	p	ør	s	t	u	øv	w
					mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	°	°	mm	mm
WITHOUT	WITH	WITHOUT	BC 11	811 159/000	40	30	25	17.46	18	15	17	1	3	23	12.2	12	26	25	25	–	–	–	3D
WITHOUT	WITH	WITH	B5 11 X	811 159/050	40	30	25	17.46	18	15	17	1	3	23	12.2	12	26	25	25	6.3	7.8	r1.5	3D
WITHOUT	WITHOUT	WITH	BC 11 X N	811 159/150	40	30	25	17.46	–	15	17	1	3	23	12.2	–	26	–	–	6.3	7.8	r1.5	3D
WITHOUT	WITH	WITHOUT	BC 12	811 309/000	49	34	32	19.46	20	17	19	1	5	25	14.2	14	28	25	25	–	–	–
WITHOUT	WITH	WITH	B5 12 X	811 309/050	49	34	32	19.46	20	17	19	1	5	25	14.2	14	28	25	25	7.3	8.8	r1.5
WITHOUT	WITHOUT	WITH	BC 12 X N	811 309/150	49	34	32	19.46	–	17	19	1	5	25	14.2	–	28	–	–	7.3	8.8	r1.5
WITHOUT	WITH	WITHOUT	BC 21	811 160/000	55	40	35	24.46	23	20	23	1	4	31	16.2	16.5	34	30	30	–	–	–	3D
WITHOUT	WITH	WITH	B5 21 X	811 160/050	55	40	35	24.46	23	20	23	1	4	31	16.2	16.5	34	30	30	10.4	10.25	r1.5	3D
WITHOUT	WITHOUT	WITH	BC 21 X N	811 160/150	55	40	35	24.46	–	20	23	1	4	31	16.2	–	34	–	–	10.4	10.25	r1.5	3D
WITHOUT	WITH	WITHOUT	BC 31	811 163/000	72	55	44.5	35.46	30	27.5	30	1	5	41	24.5	20	45	30	30	–	–	–	3D
WITHOUT	WITH	WITH	B5 31 X	811 163/050	72	55	44.5	35.46	30	27.5	30	1	5	41	24.5	20	45	30	30	17	14.5	r2	3D
WITHOUT	WITHOUT	WITH	BC 31 X N	811 163/150	72	55	44.5	35.46	–	27.5	30	1	5	41	24.5	–	45	–	–	17	14.5	r2	3D
WITHOUT	WITH	WITHOUT	BC 41	811 161/000	85	70	50	40.93	36	35	33	2	6	51	30.5	20	52	45	45	–	–	–	3D
WITHOUT	WITH	WITH	B5 41 X	811 161/050	85	70	50	40.93	36	35	33	2	6	51	30.5	20	52	45	45	18	17.5	r2	3D
WITHOUT	WITHOUT	WITH	BC 41 X N	811 161/150	85	70	50	40.93	–	35	33	2	6	51	30.5	–	52	–	–	18	17.5	r2	3D
