Long clamping arm B7

For swing clamp type: HL7
Rod end with 1:10 taper

Characteristics

• adjustable over 360°
• burnished surface
• max. pressure 125 bar

Maximum force (and thus maximum pressure) decreases proportionally with clamping arm extension. Maximum flow rate also decreases with the inertia of the clamping arm. For standard arms, please note the values stated in the table. (see HL7).

The rod must absolutely be held while clamping;
see figure 1 on the guide

Print this sheet

Long clamping arm B7 : Swing clamps with helical rotation - Quiri - 2

Tap	Bevel	Type	Reference
Tap	Bevel	Type	Reference	a	b	c	ød 0/- 0.05	e	f	g	h	s	v 0/- 0.05	w 0/- 0.02	u
				mm	mm	mm	mm	mm	mm	mm	mm	°	mm	mm	mm
WITH	WITH	B7 02	811 326/000	48	22	30	14	12	11	M6	16	10	6.6	1.5	11.5
WITH	WITH	B7 04	811 327/000	65	34	40	22	19	17	M8	25	10	10.3	1.5	20
WITH	WITH	B7 06	811 339/000	80	38	50	25	19	20	M8	25	10	11.8	1.5	20
WITH	WITH	B7 10	811 328/000	96	52	60	30	31	25	M12	27	10	15	3	18
WITH	WITH	B7 16	811 329/000	114	60	70	36	36	30	M16	35	10	18.1	3	28
