Link clamp cylinders 250 bar BL25

Double-acting - linear clamp cylinder
Maximum force at 250 bar: 4.1 to 15 kN

Supply through counter-bores under the flange ring or through gas fittings

Link clamp cylinders 250 bar BL25 : Link clamp cylinders - Quiri

Characteristics

• fastening and supply flange at the top of the clamp
• supplied with supply O-rings
• rod and connecting rods supplied with pins and circlips but with no clamping arm

Design

• steel body with anti-corrosion treatment
• steel rod treated to prevent seizing and corrosion

Options

• clamping arm: see page 99
• metal scraper

Clamping force (Fb) depending on the arm length (h) and pressure (P)
Fb = ( S x P x l x 0.9 )/h
S = piston surface in cm²
l = clamp/connecting rod centre distance in mm
P = service pressure in Bar
h = centre distance between connecting rod and clamping point in mm

Print this sheet

Link clamp cylinders 250 bar BL25 : Link clamp cylinders - Quiri - 2

Part number without flange: ******/000
Part number with standard flange: ******/100
Optional metal scraper: ******/*5*
Part numbers of packs of spare seals for BL25 clamp: 141 77x/900
Example: the part number for clamp BL25-04 is: 141771/900

Clamping force at (g+h) in mm	P Max.	Section A B	Swept volume A B	ø Rod Rod	Useful travel Total travel	Max flow rate	Type	Reference
Clamping force at (g+h) in mm	P Max.	Section A B	Swept volume A B	ø Rod Rod	Useful travel Total travel	Max flow rate	Type	Reference	a1	a2	a3	b	ø c	ø c1 max	d1	d2	g	h	i	k	ø l	ø m	ø m1	n	n1	p	q	r	r1	r2	s	t	u	ø v	ø w	ø w1	x	y	z
kN	bar	cm²	cm³	mm	mm	l/min			mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm
4.1	250	2.01	4.02	16	20	0.45	BL25-04	141 771/000	57.5	55	30	36	30	30.5	77	94.3	20.5	25	50.5	32	8.8	6.6	M6	42	21	22	14	16	20	26	G1/8’’	64	15	11	4	4	15.5	64	13
4.1	250	0.87	1.76	12	23	0.45	BL25-04	141 771/000	57.5	55	30	36	30	30.5	77	94.3	20.5	25	50.5	32	8.8	6.6	M6	42	21	22	14	16	20	26	G1/8’’	64	15	11	4	4	15.5	64	13
9.8	250	4.9	14.23	25	29	1	BL25-10	141 772/000	80	70	44	54	42	42.5	97.5	122.5	30	37.5	72.5	36	9.6	8.5	M8	56	28	24	14	20	28	36	G1/4’’	80.5	22	14	4.2	4	23.5	80.5	17
9.8	250	2.36	8.72	18	32	1	BL25-10	141 772/000	80	70	44	54	42	42.5	97.5	122.5	30	37.5	72.5	36	9.6	8.5	M8	56	28	24	14	20	28	36	G1/4’’	80.5	22	14	4.2	4	23.5	80.5	17
15	250	8.04	27.34	32	34	1.5	BL25-15	141 773/000	93.5	85	51	57	52	52.5	119	147.5	35	46	86	38.5	9.6	11	M10	69	34.5	24.5	17	26.5	31	38	G1/4’’	95	26	18	4.2	4	30	95	24
15	250	3.13	13.56	25	37	1.5	BL25-15	141 773/000	93.5	85	51	57	52	52.5	119	147.5	35	46	86	38.5	9.6	11	M10	69	34.5	24.5	17	26.5	31	38	G1/4’’	95	26	18	4.2	4	30	95	24
