Host station PS-CSM

For snap-in clamping head

Print this sheet
Host station PS-CSM : Linear cylinders - Quiri

Functional dimension X (mm) to specify with the order, for example 47-2-032 (X = 32mm) or PS-CSM-022-032 (X=32mm)

T groove according to

DIN 650



 Type Reference
a



 k



 i



 g


mm mm mm mm mm
18 PS-CSM – 018 – X M 547-1-X 25 30 10 24
22 PS-CSM – 022 – X M 547-2-X 33 37 14 32
28 PS-CSM – 028 – X M 547-3-X 43 46 18 42

Compatible products

Snap-in clamping head CSM

Single-acting - for T groove
Clamping force at 400 bar 19 kN to 78 kN

See similar accessories

Nut for threaded clamp EMF

Fine metric thread, M22x1.5 to M105x2
