Check valve HRP

Mounting on plate or in line

Operating principle

The check valve allows free flow from B to A and prevents flow from A to B. A to B is opened by hydraulic control Z. The pipe L is provided to drain any leaks.

Print this sheet
Check valve HRP : Hydraulic unit and components - Quiri
Port pressure
Type Reference
A B Z L Max flow

rate

 Weight



 Pressure ratio:

(Control/A)
bar bar bar bar l/min Kg
HRP 1 A 64 034 700 700 700 None 20 0,25 1/3
