RMGE gas spring

Diameter: 25

Features

• Bottom thread M8
• Inflating valve on the top of the piston rod
• Cannot be used in piping system
• Force can be changed by changing the pressure
• Double sealing for heavy duty

Print this sheet
RMGE gas spring : Micro gas springs - Quiri - 2
RMGE gas spring : Micro gas springs - Quiri - 3
RMGE gas spring : Micro gas springs - Quiri - 4
RMGE gas spring : Micro gas springs - Quiri - 5
Type Force Stroke C Reference Pressure Force F1 Force F2 LR LC Color 3D Model
daN mm MPa (bar) N * N * mm mm
RMGE 50 10 442061/300-S 4.5

(45)

 510 660 80 70 green 3D
16 442062/300-S 690 92 76 3D
25 442063/300-S 720 110 85 3D
38 442066/300-S 720 136 98 3D
50 442064/300-S 720 160 110 3D
63 442067/300-S 720 186 123 3D
80 442065/300-S 730 220 140 3D
100 442068/300-S 720 260 160 3D
125 442069/300-S 720 310 185 3D
100 10 442071/300-S 9

(90)

 1 020 1 320 80 70 blue
16 442072/300-S 1 380 92 76
25 442073/300-S 1 430 110 85
38 442076/300-S 1 430 136 98
50 442074/300-S 1 430 160 110
63 442077/300-S 1 430 186 123
80 442075/300-S 1 450 220 140
100 442078/300-S 1 440 260 160
125 442079/300-S 1 440 310 185
150 10 442081/300-S 13.5

(135)

 1 530 1 980 80 70 red
16 442082/300-S 2 070 92 76
25 442083/300-S 2 140 110 85
38 442086/300-S 2 150 136 98
50 442084/300-S 2 140 160 110
63 442087/300-S 2 140 186 123
80 442085/300 2 170 220 140
100 442088/300 2 160 260 160
125 442089/300 2 160 310 185
200 10 442091/300 18

(180)

 2 040 2 640 80 70 yellow
16 442092/300 2 760 92 76
25 442093/300 2 850 110 85
38 442096/300 2 860 136 98
50 442094/300 2 850 160 110
63 442097/300 2 860 186 123
80 442095/300 2 890 220 140
100 442098/300 2 880 260 160
125 442099/300 2 870 310 185

* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa

Example of order: RMGE 100 C50

NOTE : Height of RMGE is 15 mm higher than standard RMG type.

Spare kit : Not repairable.
