RMG gas spring

Diameter : 25

Features

• Body diameter: 25 mm
• Inflating valve on the top of the piston rod
• Cannot be used in piping system
• Force can be changed by changing the pressure
• Double sealing for heavy duty

Print this sheet
RMG gas spring : Micro gas springs - Quiri - 2
RMG gas spring : Micro gas springs - Quiri - 3
RMG gas spring : Micro gas springs - Quiri - 4
Type Force Stroke C Reference Pressure Force F1 Force F2 LR LC Color 3D Model
daN mm MPa (bar) N * N * mm mm
RMG 50 10 442061/000 4.5

(45)

 510 660 65 55 green 3D
16 442062/000 690 77 61 3D
25 442063/000 720 95 70 3D
38 442066/000 720 121 83 3D
50 442064/000 720 145 95 3D
63 442067/000 720 171 108 3D
80 442065/000 730 205 125 3D
100 442068/000 720 245 145 3D
125 442069/000 720 295 170 3D
100 10 442071/000 9

(90)

 1 020 1 320 65 55 blue 3D
16 442072/000 1 380 77 61 3D
25 442073/000 1 430 95 70 3D
38 442076/000 1 430 121 83 3D
50 442074/000 1 430 145 95 3D
63 442077/000 1 430 171 108 3D
80 442075/000 1 450 205 125 3D
100 442078/000 1 440 245 145 3D
125 442079/000 1 440 295 170 3D
150 10 442081/000 13.5

(135)

 1 530 1 980 65 55 red 3D
16 442082/000 2 070 77 61 3D
25 442083/000 2 140 95 70 3D
38 442086/000 2 150 121 83 3D
50 442084/000 2 140 145 95 3D
63 442087/000 2 140 171 108 3D
80 442085/000 2 170 205 125 3D
100 442088/000 2 160 245 145 3D
125 442089/000 2 160 295 170 3D
200 10 442091/000 18

(180)

 2 040 2 640 65 55 yellow 3D
16 442092/000 2 760 77 61 3D
25 442093/000 2 850 95 70 3D
38 442096/000 2 860 121 83 3D
50 442094/000 2 850 145 95 3D
63 442097/000 2 860 171 108 3D
80 442095/000 2 890 205 125 3D
100 442098/000 2 880 245 145 3D
125 442099/000 2 870 295 170 3D

* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa

Example of order : RMG 100 C50

Spare kit : Not repairable.
