RGH 750 gas spring

Features

• Shortest length gas spring
• Body diameter is same as ISO type – from 45 mm to 120 mm
• Force : from 500 daN to 5000 daN
• Stroke : from 6 mm to 125 mm
• Can be used in piping system

Print this sheet
RGH 750 gas spring : LOW PROFILE RGH GAS SPRINGS - Quiri - 2
RGH 750 gas spring : LOW PROFILE RGH GAS SPRINGS - Quiri - 3
RGH 750 gas spring : LOW PROFILE RGH GAS SPRINGS - Quiri - 4
Type Force Stroke C Reference Pressure Force F1 Force F2 LR LC Mass
daN mm MPa (bar) N* N* mm mm Kg
RGH 750 6 442361/000 15

(150)

 7 370 10 450 62 56 0.65
12.7 442362/000 11 280 75.4 62.7 0.68
19 442363/000 11 260 88 69 0.71
25 442364/000 11 350 100 75 0.74
38 442365/000 11 500 126 88 0.80
50 442366/000 11 640 150 100 0.85
63 442367/000 11 370 176 113 0.91
80 442368/000 11 650 210 130 0.98
100 442369/000 11 740 250 150 1.07
125 442370/000 11 820 300 175 1.18

* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa

Example of order : RGH 750 C50
Spare kit : 896519/000
Composition : Guide ring, seals, valve and lubricant.

RGH 750 gas spring : LOW PROFILE RGH GAS SPRINGS - Quiri - 5

Product accessories

RGF 10

841074/000

RGF 53

841119/000

RGF 54

841139/000

RGF 4

841032/000

RGF 3

841027/000

RGHF 12

841132/100

RGF 9

841069/100
