RGH 5000 gas spring

Features

• Shortest length gas spring
• Body diameter is same as ISO type – from 45 mm to 120 mm
• Force : from 500 daN to 5000 daN
• Stroke : from 6 mm to 125 mm
• Can be used in piping system

Print this sheet
RGH 5000 gas spring : LOW PROFILE RGH GAS SPRINGS - Quiri - 2
RGH 5000 gas spring : LOW PROFILE RGH GAS SPRINGS - Quiri - 3
RGH 5000 gas spring : LOW PROFILE RGH GAS SPRINGS - Quiri - 4
Type Force Stroke C Reference Pressure Force F1 Force F2 LR LC Mass
daN mm MPa (bar) N* N* mm mm Kg
RGH 5000 25 442961/000 15

(150)

 49 780 73 930 140 115 8.20
38.1 442962/000 74 800 166.2 128.1 8.60
50 442963/000 75 430 190 140 8.90
63.5 442964/000 75 420 217 153.5 9.30
80 442965/000 76 130 250 170 9.70
100 442966/000 76 290 290 190 10.30

* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa

Example of order : RGH 5000 C50
Spare kit : 896523/000
Composition : Guide ring, seals, valve and lubricant.

RGH 5000 gas spring : LOW PROFILE RGH GAS SPRINGS - Quiri - 5

Product accessories

RGF 3

841030/000

RGF 4

841035/000

RGF 10

841075/000

RGHF 12

841135/100

RGF 101

841176/000

RGHF 53

841185/000

RGHF 54

841187/000

RGF 9

841072/100
