RGP 4200 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri close pdf print video more home burger search arrow

Hydraulic cylinders and components, hydraulic systems, gas springs & shell and tube heat exchangers : Quiri

RGP 4200 gas spring

Features

• Diameter from 19 to 150 mm
• Stroke : from 7 to 125 mm
• Force : from 170 to 9500daN (9.5t)
• Very compact size
• Solid design (no welding)

Print this sheet
RGP 4200 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 2
RGP 4200 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 3
RGP 4200 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 4
RGP 4200 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 5
Type Force Stroke C Reference ISO Pression Force F1 Force F2 LR LC Mass 3D Model
daN mm MPa (bar) N* N* mm mm Kg
RGP 4200 16 443364/000-S 15

(150)

(!)

 42 420 62 890 90 74 3.00 3D
19 443365/000-S 63 870 96 77 3.10 3D
25 443366/000-S X 65 610 108 83 3.30 3D
32 443367/000-S 66 790 122 90 3.50 3D
38 443368/000-S X 67 670 134 96 3.60 3D
50 443369/000-S X 68 770 158 108 4.00 3D
63 443370/000-S X 69 520 184 121 4.30 3D
75 443371/000-S 70 020 208 133 4.60 3D
80 443372/000-S X 70 170 218 138 4.70 3D
100 443373/000-S X 70 700 258 158 5.30 3D
125 443374/000-S X 71 960 308 183 5.90 3D

* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa

Example of order : RGP 4200 C50
Spare Kit : 896534/000.
Composition : Guide ring, seals, valve and lubricant.

RGP 4200 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 6

(!) There is a blue sticker on the gas spring body when it is inflated with a special pressure (<15 MPa)

RGP 4200 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 7

Product accessories

RGF 3

841029/000

RGF 4

841034/000

RGF 9

841228/000

RGF 10

841075/000

RGF 53

841121/000

RGF 54

841141/000

Connections for RGP gas springs
