RGP 2400 gas spring

Features

• Diameter from 19 to 150 mm
• Stroke : from 7 to 125 mm
• Force : from 170 to 9500daN (9.5t)
• Very compact size
• Solid design (no welding)

Print this sheet
RGP 2400 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 2
RGP 2400 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 3
RGP 2400 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 4
RGP 2400 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 5
Type Force Stroke C Reference ISO Pressure Force F1 Force F2 LR LC Mass 3D Model
daN mm MPa (bar) N* N* mm mm Kg
RGP 2400 16 443344/000-S 15

(150)

(!)

 23 860 36 120 77 61 1.50 3D
19 443345/000-S 36 560 83 64 1.54 3D
25 443346/000-S X 37 370 95 70 1.66 3D
32 443347/000-S 37 810 109 77 1.78 3D
38 443348/000-S X 38 200 121 83 1.88 3D
50 443349/000-S X 38 630 145 95 2.10 3D
63 443350/000-S X 38 920 171 108 2.30 3D
75 443351/000-S 39 110 195 120 2.50 3D
80 443352/000-S X 39 140 205 125 2.60 3D
100 443353/000-S X 39 360 245 145 2.90 3D
125 443354/000-S X 39 460 295 170 3.30 3D

* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa

Example of order : RGP 2400 C50
Spare kit : 896533/000
Composition : Guide ring, seals, valve and lubricant.

RGP 2400 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 6

(!) There is a blue sticker on the gas spring body when it is inflated with a special pressure (<15 MPa)

RGP 2400 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 7

Product accessories

RGF 53

841120/000

RGF 54

841140/000

RGF 3

841028/000

RGF 4

841033/000

RGF 10

841075/000

RGF 9

841227/000
