RGP 1000 N gas spring

Features

• Diameter from 19 to 150 mm
• Stroke : from 7 to 125 mm
• Force : from 170 to 9500daN (9.5t)
• Very compact size
• Solid design (no welding)

Print this sheet
RGP 1000 N gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 2
RGP 1000 N gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 3
RGP 1000 N gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 4
RGP 1000 N gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 5
Type Force Stroke C Reference ISO Pressure Force F1 Force F2 LR LC Mass 3D Model
daN mm MPa (bar) N* N* mm mm Kg
RGP 1000 10 443851/000-S 15

(150)

(!)



 9 240 13080 58 48 0.56
13 443852/000-S X 13 360 64 51 0.58 3D
16 443854/000-S 13 550 70 54 0.60 3D
19 443855/000-S 13 690 76 57 0.63 3D
25 443856/000-S X 14 050 88 63 0.70 3D
32 443857/000-S 14 260 102 70 0.74 3D
38 443858/000-S X 14 320 114 76 0.80 3D
50 443859/000-S X 14 590 138 88 0.92 3D
63 443860/000-S X 14 660 164 101 1.02 3D
75 443861/000-S 14 730 188 113 1.13 3D
80 443862/000-S X 14 750 198 118 1.16 3D
100 443863/000-S X 14 850 238 138 1.35 3D
125 443864/000-S X 14 800 288 163 1.56 3D

* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa

Example of order: RGP 1000 C50 N
Spare Kit : 896531/000.
Composition : Guide ring, seals, valve and lubricant.

RGP 1000 N gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 6

(!) There is a blue sticker on the gas spring body when it is inflated with a special pressure (<15 MPa)

RGP 1000 N gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 7

Product accessories

RGF 53

841118/000

RGF 10

841074/000

RGF 54

841139/000

RGF 4

841032/000

RGF 3

841027/000

RGF 9

841225/000

Connections for RGP gas springs

View similar products

RGP 500 gas spring

RGP 4200 gas spring

RGP 170 gas spring

RGP 320 gas spring
