CONNECTION WITH CONNECTOR for RGPR 750/1000/1500/2400 (M6 thread)

Print this sheet

CN 11 WITH STRAIGHT CONNECTOR

CONNECTION WITH CONNECTOR for RGPR 750/1000/1500/2400 (M6 thread) : CONNECTIONS FOR RGP GAS OUTLETS (M6 thread) - Quiri

CN 11 WITH 90° ELBOW CONNECTOR

CONNECTION WITH CONNECTOR for RGPR 750/1000/1500/2400 (M6 thread) : CONNECTIONS FOR RGP GAS OUTLETS (M6 thread) - Quiri - 2
Type Jmin.

(mm)
RGPR 350 141.5
RGPR 500 143.5
RGPR 750 148
RGPR 1000 150.5
RGPR 1500 157
RGPR 2400 163



View similar products

HORIZONTAL CONNECTION for RGPR 750/1000/1500/2400 (M6 thread)

MINI BLOCK MANIFOLD for RGPR 750/1000/1500/2400 (M6 thread)
