CONNECTION WITH CONNECTOR for RGPR 4200/6600/9500 (G1/8” Thread)

Print this sheet

CN 11 WITH STRAIGHT CONNECTOR

CONNECTION WITH CONNECTOR for RGPR 4200/6600/9500 (G1/8” Thread) : CONNECTIONS FOR RGP GAS OUTLETS (G1/8″ tapping) - Quiri
CONNECTION WITH CONNECTOR for RGPR 4200/6600/9500 (G1/8” Thread) : CONNECTIONS FOR RGP GAS OUTLETS (G1/8″ tapping) - Quiri - 2

CN 11 WITH 90° ELBOW CONNECTOR

CONNECTION WITH CONNECTOR for RGPR 4200/6600/9500 (G1/8” Thread) : CONNECTIONS FOR RGP GAS OUTLETS (G1/8″ tapping) - Quiri - 3
CONNECTION WITH CONNECTOR for RGPR 4200/6600/9500 (G1/8” Thread) : CONNECTIONS FOR RGP GAS OUTLETS (G1/8″ tapping) - Quiri - 4
Type Jmin.

(mm)
RGPR 4200 152
RGPR 6600 164
RGPR 9500 179
